Orifice Flanges


C-Way Engineering Exports is one of the most professional orifice flanges manufacturers, suppliers, and exporters in India, we are featured by high-quality products and competitive prices. We produce international standards ASME/ANSI/IS/DIN/BS/JIS orifice flanges. Standard sizes of carbon steel and stainless steel orifice flanges are readily available in the stock to deliver immediately.

Orifice flanges are specialized flanges designed for use with orifice meters to measure the flow rate of fluids in piping systems. They provide a means of installing orifice plates or other flow measurement devices directly into the pipeline while also providing access for maintenance or replacement. Orifice flanges are commonly used in industries such as oil and gas, petrochemical, chemical processing, and water treatment.

Orifice flanges consist of a standard flange with additional features to accommodate the installation of an orifice plate or flow measurement device. They typically have smaller bore or tapped holes on one side of the flange where the orifice plate is installed. The orifice plate is positioned between the two flanges, creating a constriction in the flow path that allows for accurate measurement of fluid flow rate.

Orifice flanges can have either a raised face (RF) or ring-type joint (RTJ) facing to provide a sealing surface for gaskets. The flanges are available in various pressure ratings, sizes, materials, and facing configurations to suit different application requirements.

All Flanges with standard sizes and materials are readily available in stock for immediate delivery. "Looking for large diameter Flanges ? Contact us today for Customized Flanges.


Applications of Orifice Flanges


Oil and Gas Industry: They are used in oil and gas production facilities, refineries, pipelines, and distribution networks for flow measurement and control of hydrocarbons and other fluids.

Petrochemical Plants: Orifice Flanges find application in petrochemical plants for measuring and monitoring the flow of chemical fluids in process piping systems.

Chemical Processing: They are employed in chemical processing plants for flow measurement and control of corrosive fluids, acids, and solvents.

Water Treatment: Orifice Flanges are used in water treatment plants, desalination facilities, and distribution networks for measuring and monitoring the flow of water and wastewater.

Power Generation: They find applications in power generation facilities for flow measurement and control of steam, condensate, and cooling water in boiler systems and power plants.

Quick Enquiry Form

Advantages of Orifice Flange


Accurate Flow Measurement: Orifice Flanges provide a reliable and cost-effective method for measuring fluid flow rate in piping systems. Versatility: They can accommodate various types of orifice plates, flow measurement devices, and accessories to meet specific application requirements. Access for Maintenance: Orifice Flanges allow for easy access to the orifice plate for maintenance, inspection, or replacement without the need to disassemble the entire piping system. Compatibility: They are compatible with standard flanges, valves, and fittings, allowing for seamless integration into existing piping systems.

Testing


We conduct a series of testing procedures to ensure the quality, reliability, and performance of our Flanges.

These tests are conducted at various stages of manufacturing, from raw material inspection to the final product testing.

  • Dimensional Inspection
  • Visual Inspection
  • Non-Destructive Testing
    • Ultrasonic Testing
    • Magnetic Particle Testing
    • Liquid Penetrant Testing
    • Radiographic Testing
  • Mechanical Testing
    • Tensile Testing
    • Hardness Testing
  • Chemical Analysis
  • Intergranular Corrosion Testing
  • Pressure Testing
  • Corrosion Resistance Testing

Type of Flanges Specification, Grades, and Material

Flanges Specifications
Flanges Types Orifice Flange
Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS ASA 150, ASA 300, PN 6,10,16,25, 40,64,100,160 ETC. available with NACE MR 01-75
Size 1/2″ (15 NB) to 48″ (1200 NB)
Standard ANSI/ASME B16.5, ANSI/ASME B16.47 Series A and Series B, MSS SP44, ASA, API 605, API 6A, AWWA, As per Custom Drawings
Pressure Rating Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc
Type Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ), Lap-Joint Face (LJF), Large Male-Female (LMF), Small Male-Female (SMF), Large Tongue & Groove, Small Tongue, Groove



Grades
Stainless Steel ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L
Duplex Steel ASTM/ASME A/SA 789, 790 – UNS NO S 31803, S 32205, S 32550, S 32750, S 32760.
Carbon Steel ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8
Alloys Steel Flanges ASTM A182 F1, F5, F9, F11, F22, F91
Special Alloy Flanges Duplex, Super Duplex, Nickel Alloys
Flange Face Type Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Coating/Surface Treatment Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Nickel Alloys Nickel Alloys 200, Nickel Alloys 201
Hastelloy Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000, Hastelloy C-4, Hastelloy X, Hastelloy B, Hastelloy N, Hastelloy G
Inconel Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750 , Inconel 690, Inconel 602, Inconel 617, Inconel 925, Inconel A-289, Inconel AL-6XN, AL-904L


Certification and Documentation

As per International Industrial standards we provide all the necessary certifications. We provide certification and documentation, including material test reports (MTRs), inspection reports and compliance certificates to ensure product quality and compliance with standards and specifications.

These testing procedures ensure that flanges manufactured by us meet the standards, performance, and regulatory compliance. Our flanges meet stringent quality requirements and provide reliable performance in different industrial applications.
